Ricoh TH-C1b - Checking the Image with the Trimming Pattern

10 February 2005 SKEWED, TRAPEZOID, AND PARALELLOGRAM IMAGES
4-29
Trouble-
shooting
4.6.4 CHECKING THE IMAGE WITH THE TRIMMING PATTERN
Print out 5, A3 Trimming Patterns from
SP5-955 (value: 11)
Skewed
Parallelogram
See Action 1 (Skewed
Images)
See Action 2
(Parallelogram Image
A
djustment)
