Ricoh TH-C1b - SP Mode Settings for IEEE 802.11 B Wireless LAN

PRINTER OPTIONS 10 February 2005
1-58
10. Press “Return to Default” to initialize the wireless LAN settings.
Press “Yes” to initialize the following settings:
• Transmission mode
• Channel
• Transmission Speed
• WEP
• SSID
• WEP Key
SP Mode Settings for IEEE 802.11b Wireless LAN
The following SP commands and UP modes can be set for IEEE 802.11b
SP No. Name Function
5840 006 Channel MAX Sets the maximum range of the channel settings for the
country.
5840 007 Channel MIN Sets the minimum range of the channels settings
allowed for your country.
5840 011 WEP Key Select Used to select the WEP key (Default: 00).
UP mode Name Function
SSID Used to confirm the current SSID setting.
WEP Key Used to confirm the current WEP key setting.
WEP Mode Used to show the maximum length of the string that can
be used for the WEP Key entry.
