SP3-XXX: (Process)
3
Mode No.
(Class 1, 2, and 3)
Function / [ Setting ]
Forced Process Control
1 Execute
Does a forced process control, and displays the result as
one of the following codes.
001
2 Display Displays the completion code.
• 1: Normal termination
• 99: Stop (Interruption due to SC or door open)
• 103: Error (ID sensor inactive
→
Defective ID sensor,
Defective circuit, Defective BCU board)
• 104: Error (ID sensor unable to receive light
→
Defective OPC belt, Dirty OPC belt, Defective ID
sensor, Defective circuit, Defective BCU board)
• 105: Error (ID sensor unable to receive reflection from
OPC
→
Same as “104”)
• 110: Error (Cyan: ID sensor unable to detect correct
image)
• 111: Error (Magenta: ID sensor unable to detect
correct image)
• 112: Error (Yellow: ID sensor unable to detect correct
image)
• 113: Error (Cyan: ID sensor unable to detect correct
image)
• 114: Error (Magenta: ID sensor unable to detect
correct image)
• 115: Error (Yellow: ID sensor unable to detect correct
image)
• 116: Error (Black: ID sensor unable to detect correct
image)
• 118: Error (Black image not detected)
• 123: Error (Development bias error; Black ID sensor
unable to detect correct image)
Solutions for codes 110 to 123:
• Poor connection to the development unit
• Dirty development bias terminal
• Abnormal development bias
• PCU not installed correctly
• LD unit defective
• Abnormal charge corona voltage
• Defective BICU
Lubricant Interval
1 Interval
Sets the process control interval. Process control for this
SP is done only after job end.
[0 ~ 1000 / 200 / 10 sheets/step]
• 0: Disables automatic process control
003*
2 Forced Interval
Sets the process control interval. Process control for this
SP is done during a job if the counter reaches the value
(N1 + N2).
If the counter is between N1 and N2, process control is
done after job end.
N1: the value specified with SP3-003-1.
N2: the value specified with this SP.
[0 ~ 5000 / 500 / 10 sheets/step]
