PRINTER OPTIONS 10 February 2005
1-52
1.15.3 IEEE1394 INTERFACE (B581)
!CAUTION
Unplug the main machine power cord before starting the following
procedure.
NOTE: You can only install one of these network interfaces at the same time: IEEE
802.11b (Wireless LAN), IEEE1284 (Parallel/Centronics), IEEE1394
(FireWire), or Bluetooth.
1. Remove the slot cover [A] from I/F Card Slot B (! x 2).
2. Install the FireWire board [B] (Knob-screw x 2).
NOTE: Use a screwdriver when you tighten the knob-screws. Do not tighten
them manually. It can cause this board to disconnect from the machine.
B581I001.WMF
[A]
[B]
To Next Page
