Ricoh TH-C1b - Drive Power Path

OVERVIEW 10 February 2005
6-4
Drive Power Path
Motor (Type) Drives ...
Scanner [B]
(Stepper)
• Scanner motor gear [C]
Development [I
K&C
]
(DC brushless)
• Development clutches [H
K, C
] → Development unit for K and C
Development [I
Y&M
]
(DC brushless)
• Development clutches [H
Y, M
] → Development unit for Y and M
• OPC belt cleaning clutch [L] → OPC belt cleaning unit
Main [G]
(DC brushless)
• OPC belt [K] with the flywheel [J]
• Image transfer belt [M]
Fusing Unit [D]
(DC brushless)
• Fusing unit [S]
• Paper exit unit [A]
• Image transfer belt cleaning clutch [E] → Image transfer belt
cleaning unit
• Registration clutch [Q] → Registration roller
• Paper transfer roller
• Belt cleaning contact solenoid [F] → Image transfer belt cleaning
unit contact mechanism
• Paper transfer solenoid [R] → Paper transfer roller contact
mechanism
• Interchange unit and one-bin tray
Paper Feed [N]
(Stepper)
• Paper feed clutch [O
1,2
] → Paper pick-up roller
• Vertical transport clutch [P
1,2
]
B156V108.WMF
[A] [B] [C] [D] [E] [F] [G]
[H
K
]
[I
K
,
C
]
[J]
[K][L][M][N][O
2
]
[P
2
]
[Q]
[R]
[S]
[H
C
]
[I
Y
,
M
]
[O
1
]
[P
2
]
[H
Y
]
[H
M
]
