SERVICE PROGRAM MODE 10 February, 2005
5-58
SP7-XXX: (Data Log)
7
Mode No.
(Class 1, 2, and 3)
Function / [ Setting ]
Operation Time 001*
1 Operation Time Displays the main motor operation time.
[0000000 ∼ 9999999 / 0 / 1 minute/step]
Logging this operation time helps identify the cause of a
difficulty by analyzing the correlation between the
printing count and the OPC-belt operation time.
Waste Tnr Cnter (Waste Toner Counter)
1 OPC Displays the waste toner bottle counters.
[0 ~ 65535 / 0 / 1 /step]
106*
2 Belt [0 ~ 65535 / 0 / 1 /step]
Total SC Counter 401*
1 SC Counter Displays how many times SC codes have been output.
[0 ~ 9999 / 0 / 0 time/step]
SC History
1 Latest
2 Latest 1
3 Latest 2
4 Latest 3
5 Latest 4
6 Latest 5
7 Latest 6
8 Latest 7
9 Latest 8
403
10 Latest 9
Displays the latest ten SC codes.
Total Paper Jam Counter 502*
1 Total Paper Jam
Counter
Displays the total number of jams detected.
[0 ~ 9999 / 0 / 0 /step]
Total Original Jam Counter 503
1 Total Original Jam
Counter
Displays the total original jam count.
[0 ~ 9999 / 0 / 0 /step]
Paper Jam Location
1 Initial jam
3 main003 (Tray 1: ON)
4 main004
(Tray 2: Non Feed)
5 main005
(Tray 3: Non Feed)
6 main006
(Tray 4: Non Feed)
7 main007
(Bypass: Non Feed)
8 main008
(1st Relay ON)
9 main009
(2nd Relay: ON)
10 main010
(3rd Relay: ON)
504*
12 main012 (Registration
from Tray)
Displays the number of jams according to the location
where they were detected.
[0 ~ 9999 / 0 / 0 /step]
To Next Page
