COPIER (B156/B220) 10 February 2005
1-6
1.2.4 INSTALLATION PROCEDURE
!CAUTION
Unplug the machine power cord before starting the following procedure.
If the optional paper tray or the optional LCT will be installed at the same time,
place the copier on the paper tray unit or the LCT first, then install the copier and
the other options.
NOTE: Keep the shipping retainers after installing the machine. They will be
reused when the machine is moved to another location in the future.
1. Remove the tapes.
2. Open the front cover [A] and remove the shipping retainer [B].
B156I504.WMF
B156I505.WMF
B156I506.WMF
[A]
[B]
To Next Page
