Ricoh TH-C1b - Image Transfer

OVERVIEW 10 February 2005
6-6
Image Transfer
1. Charge corona wire cleaner motor
2. Quenching lamp
3. ID sensor
4. Belt mark sensor
5. T/B waste toner bottle switch
6. T/B waste toner sensor
7. O/B waste toner sensor
8. Fusing entrance sensor
9. O/B waste toner bottle switch
10. Transfer belt sensor
11. Pressure roller thermofuse
12. Pressure roller thermistor
13. Heating roller thermistor
14. Pressure roller fusing lamp
15. Heating roller fusing lamp
16. Oil overflow sensor
17. Heating roller thermostat
18. Oil end sensor
T/B: Image transfer belt
O/B: OPC belt
B156D004.WMF
1
2
3
4
5
6
7
8
9
10
11
1213
15
16
14
17
18
