Ricoh TH-C1b - Duplex Unit (B509); Accessory Check

10 February 2005 DUPLEX UNIT (B509)
1-35
Installation
1.10 DUPLEX UNIT (B509)
1.10.1 ACCESSORY CHECK
Check the quantity and condition of the accessories against the following list.
No. Description Q’ty
1 Duplex Unit 1
2 Upper Bracket 1
3 Rear Holder Bracket 1
4 Front Holder Bracket 1
5 Clip 2
6 Tapping Screw – M4x6 3
7 Tapping Screw – M3x6 1
B509I101.WMF
1
2
3
4
5
6
7
