SERVICE PROGRAM MODE 10 February, 2005
5-56
6
Mode No.
(Class 1, 2, and 3)
Function / [ Setting ]
ADF Free Run 009
1 ADF Free Run Executes an ADF free run.
[0 ∼ 1 / 0 / 1 /step]
• 0: End
• 1: Start
ADF Stamp Position 010
1 ADF Stamp Position Adjusts the stamp position of the optional ADF.
[–5.0 ∼ 5.0 / 0 / 0.1 mm/step]
Staple Position 050
1 Staple Position Adjusts the staple position of the optional finisher.
[–3.5 ∼ 3.5 / 0.0 / 0.5 mm/step]
Finisher Input Check
1 Entrance
2 Tray Exit
4 Staple Entrance
5 Stapler Home Position
6 Jogger Fence Home
Position
8 Feed-out Belt Home
Position
9 Stapler Tray Paper
10 Stapler Rotation Home
Position
11 Staple
14 Staple Sheet
17 Exit Plate Home
Position
18 Tray Shift Home
Position
21 Stack Height
23 Tray Lower Limit
35 Paper Limit
101 500 Fin Entrance
102 500 Fin Exit
103 500 Fin Jogger Home
Position
104 500 Fin Top Cover
105 500 Fin Height
117
106 500 Fin Lever
Displays the signals received from sensors and switches
in the finisher.
See section 5.1.4
107 500 Fin Upper Limit
108 500 Fin Near Limit
109 500 Fin Staple Cover
110 500 Fin Stapler Home
Position
111 500 Fin Staple End
112 500 Fin Staple
117
113 500 Fin Stapler Lock
Displays the signals received from sensors and switches
in the finisher.
See section 5.1.4
Output Check
1 Fin All Off
118
2 Upper Transfer Motor
Switches on each electrical component of the finisher.
See section 5.1.5
