Ricoh TH-C1b - Page 263

SERVICE PROGRAM MODE 10 February, 2005
5-60
7
Mode No.
(Class 1, 2, and 3)
Function / [ Setting ]
103 main103 (Finisher
Staple)
104 main104 (Finisher
Stack Feed-out)
105 main105 (Finisher
Paper Taking out)
107 main107 (Finisher
Drive Error)
108 main108 (Finisher
Tray Lift Error)
109 main109 (Finisher
Jogger Error)
110 main110 (Finisher
Tray Shift Error)
111 main111 (Finisher
Stapler Error)
112 main112 (Finisher
Stack Feed-out)
114 main114 (Finisher
Feed out Error)
504*
115 main115 (Finisher No
Response)
Displays the number of jams according to the location
where they were detected.
[0 ~ 9999 / 0 / 0 /step]
Original Jam Detection
1 Initial jam
5 Regist Sensor005
6 Exit 006 Exit = Original Trailing Edge Sensor (S9)
505
7 Inverter Sensor 007 Inverter Sensor = Original Reverse
Sensor (S10)
55 Regist Sensor 055
56 Exit 056 Exit = Original Trailing Edge Sensor (S9)
505
57 Inverter Sensor 057 Inverter Sensor = Original Reverse
Sensor (S10)
Jam Count by Paper Size
5 A4 LEF
6 A5 LEF
14 B5 LEF
38 LT LEF
44 HLT LEF
132 A3 SEF
Displays the number of jams according to paper size.
[0 ~ 9999 / 0 / 1 /step]
133 A4 SEF
134 A5 SEF
141 B4 SEF
142 B5 SEF
160 DLT SEF
164 LG SEF
166 LT SEF
172 HLT SEF
506*
255 Others
Displays the number of jams according to paper size.
[0 ~ 9999 / 0 / 1 /step]
