SERVICE PROGRAM MODE 10 February 2005
5-104
Reading SP5-803
-XXX
Description
0 1
26
Fuser Entrance
Sensor
Fusing entrance sensor
Detected Not detected
27
PCU-Coil Paper
Check
Transfer belt sensor
Detected Not detected
28
PPI-Level: Bit 0 High voltage power
supply unit
Detected Not detected
29
PPI-Level: Bit 1 High voltage power
supply unit
Detected Not detected
30 Toner End: M Toner end sensor: M Not end End
31 Toner End: C Toner end sensor: C Not end End
32 Toner End: Y Toner end sensor: Y Not end End
33 Toner End: K Toner end sensor: K Not end End
38
O/B Waste Toner
Sensor
OPC belt waste toner
sensor
Full Not full
39
O/B Waste Toner
Switch
OPC belt waste toner
bottle switch
Set Not set
40 Belt Mark Belt mark sensor Not detected Detected
42
T/B Waste Toner
Sensor
Transfer belt waste toner
sensor
Full Not full
43
T/B Waste Toner
Switch
Transfer belt waste toner
bottle switch
Set Not set
44 LD 5V Cover Interlock switch Closed Open
45 Left Cover Closed Open
46 Right Upper Cover Closed Open
47 Front Cover Closed Open
49 Main Motor Lock Main motor lock Locked Not locked
50
Paper Feed Motor
Lock
Paper feed motor lock
Locked Not locked
51 Polygon Motor Lock Polygon motor lock Locked Not locked
52 1 Bin Set Set Not set
53 1 Bin Paper Sensor Detected Not detected
54
Dev. Motor 1: Lock Development motor for
black and cyan
Locked Not locked
55
Dev. Motor 2: Lock Development motor for
yellow and magenta
Locked Not locked
56 PSU-Fan Lock PSU fan motor lock Locked Not locked
57 Fuser-Fan lock Fusing fan motor lock Locked Not locked
60 Duplex Connection Duplex unit Not connected Connected
61 Bank 1 Connection 1st optional paper tray Not connected Connected
62 Bank 2 Connection 2nd optional paper tray Not connected Connected
63
Finisher
Connection
Finisher Connection
Not connected Connected
64 Bridge Exit Sensor Detected Not detected
65
Bridge Relay
Sensor
Detected Not detected
66 Bridge Set Sensor Set Not set
67 Bridge Right Cover Closed Open
68 Bridge Left Cover Closed Open
69
Bank Upper Relay Relay Sensor 3 (optional
paper tray unit)
No paper Paper present
