RKC INSTRUMENT PF900 User Manual

5. OPERATION
IMR02L04-E3
5-5
Control action at Pattern end and Proportional cycle time may be set in the Setup setting mode.
PV
K END.P
M:S SV
F50.07R 00000
Control action at
Pattern end
Select Control state at pattern end.
PID control or Heat/Cool PID control,
Position proportioning PID control (with FBR input):
00000: Control continued (Factory set value)
00001: Control stop
Setting is still effective when using Output program function.
Position proportioning PID control (without FBR input or at
FBR burnout):
00000: Control continued (Factory set value)
00001: Open-side output OFF, Close-side output OFF
00002: Open-side output OFF, Close-side output ON
00003: Open-side output ON, Close-side output OFF
Set the Intensity factor of ramp/soak
stabilizer.
0000.5: 0.5 (Factory set value)
[Range: 0.0 to 1.0]
PV
RSS.A
J
M:S SV
F50.08R 0000.5
Intensity factor of
ramp/soak stabilizer
OUT1
proportional cycle time

Set OUT1
p
roportional cycle
time.
0020.0: 20.0 (Factory set value)
[Range: 0.1 to 100.0 seconds]

Continued from the
previous parameter
F50.11:
OUT2 proportional cycle time
F50.12:
OUT2 minimum ON/OFF
time of proportioning cycle
F50.13:
OUT3 proportional cycle time
F50.14:
OUT3 minimum ON/OFF
time of proportioning cycle
(Not used for this example)
 
Return to
Function block 50
(F50.)
PV
L o1.TM
M:S SV
F50.10R 00000
OUT1 minimum
ON/OFF time of
proportioning cycle
Set OUT1 minimum ON/OFF
time of proportioning cycle.
00000: 0 (Factory set value)
[Range: 0 to 1000 ms]

PV
L-CT1
M:S SV
F50.09R 0020.0
