3. WIRING
IMR02L04-E3
3-10
Number of outputs and output types must be specified when ordering. The specifications of each output
are as follows.
Specification
code
Output type Specifications
N
None
M
Relay contact
250 V AC 3 A (Resistive load)/30 V DC 1 A (Resistive load)
1a contact
V
Voltage pulse
0/12 V DC (Allowable load resistance: 600 or more)
Allowable load resistance is 300 or more (within 40 mA)
when using only OUT1.
4
Voltage
0 to 5 V DC (Allowable load resistance: 1 k or more)
5
0 to 10 V DC (Allowable load resistance: 1 k or more)
6
1 to 5 V DC (Allowable load resistance: 1 k or more)
7
Current
0 to 20 mA DC (Allowable load resistance: 600 or less)
8
4 to 20 mA DC (Allowable load resistance: 600 or less)
T
Triac
Output method: Zero-cross output
Allowable load current: 0.5 A
(Ambient temperature 40 C or less)
[Derating:
0.02 A/C when ambient is
40
C or more.]
Load voltage: 75 to 250 V AC
Minimum load current: 30 mA
ON voltage: 1.6 V or less
(at maximum load current)
D
Open collector
Allowable load current: 100 mA
Load voltage: 30 V DC or less
ON voltage: 2 V or less (at maximum load current)
Leakage current at OFF: 0.1 mA or less
Assign Control output, Transmission output or Event output as described in the table below.
Output terminal Details of output Setting screen
OUT1 Control output, Transmission output * Engineering mode F31.01:
OUT1 assignment (LoGC1)
[Refer to P. 4-36.]
OUT2 Control output, Transmission output or
Event output
Engineering mode F32.01:
OUT2 assignment (LoGC2)
[Refer to P. 4-36, 37.]
* Transmission output of OUT1 is only available for Output program.
Refer to the description below for general output assignment for each control action.
Control action Details of assignment
PID control OUT1: Control output: Manipulated output value 1 (MV1)
(reverse action or direct action)
OUT2: Transmission output or Event output
Heat/Cool PID control OUT1: Control output: Manipulated output value 1 (MV1) [heat-side]
OUT2: Control output: Manipulated output value 2 (MV2) [cool-side]
Position proportioning
PID control without FBR
OUT1: Control output: Manipulated output value 1 (MV1)
[open-side output]
OUT2: Control output Manipulated output value 2 (MV2)
[close-side output]
Make sure to assign the output as described for the Position proportioning
PID control.
To Next Page
