7. INTERNAL WEB PAGES
The master station includes a set of web pages that may be remotely accessed via Ethernet. They can
be used for setting up the system, examining the system for any faults or alarms and also for
controlling the actuators on the network (provided the Interlock permission is set to allow this feature).
If the master station is connected to an Ethernet Network it will act as a web server and any computer
within that network can connect to the master station. The master station can also be configured and
the field network set up by using these web pages. The host system or computer connected via the
Ethernet Network or directly will need a web browser such as Internet Explorer to access the master
station web pages.
7.1 Making an Internet / Intranet Connection
Connect the master station to an Ethernet host as described in section 5, or connect via a suitable
router to the internet / intranet. A computer can be connected directly to the master station using the
configuration port.
Start the browser and enter the IP address of the master station. The default address is 10.200.1.1, so
the address is http://10.200.1.1. The browser will then access the master station and bring up the
opening page of the master station. In order to log in as a verified user, enter a user name of admin
and a password of admin. (The default password should be altered as soon as convenient to prevent
unauthorised access to the system.)
Once entry to the web pages has been made, if no changes to the display or information is made for a
few minutes, the system will automatically log out and the user/password must be re-entered.
