rotork p3 - Pakscan 2 Loop Option Module Event Logger [Event Log]

P3 - Pakscan Master Station Technical Manual
70 of 136 Publication PUB059-002-00 Issue 06/15
7.5.9 Pakscan 2 Loop Option Module Event Logger [Event Log]
Fig 47: Wired Option Module Event Logger pop-up
The event logger shows the last occurrence of the listed events and, in the case of an ESD, where the
signal originated.
Controls - Available to all user levels
Print : Prints the logger data to a printer attached to the computer.
Save : Saves the logger data to a file on the computer.
Refresh : Updates the screen with any new data.
Event Log
Controls
This screen is accessible to Read, Write and Administrator user levels.
Close pop-up
