P3 - Pakscan Master Station Technical Manual
8 of 136 Publication PUB059-002-00 Issue 06/15
A master station fitted with the wired network only requires the PS720 module that fits in to the back
plane. A master station fitted with wireless requires a module to be fitted to the back plane (in option
1) and connected to this module, a P3W coordinator module (PS722).
Fig 3: The Pakscan 3 Single Master Station – option: Wireless
Fig 4: The Pakscan 3 Hot Standby Master Station – option: Wireless
Fig 5: The P3W (Pakscan 3 Wireless) coordinator – PS722.
One required for single channel master stations, two for hot standby
master stations. The P3W repeater (a device for extending the
range of wireless) and the P3W WMA look identical to this.
