Sea-doo 2005 4-Tec models User Manual

Section 08 STEERING SYSTEM
Subsection 02 (OFF-POWER ASSISTED STEERING SYSTEM (O.P.A.S.))
F18K0PA
1 1
1. Socket screws
GTX Series, Wake and RXT Models
Remove Oetiker clamp no. 9 to remove water
hose no. 10 from the cylinder support no. 6.
3
F18K0QA
1
2
1. Oetiker clamp
2. Water hose
3. Cylinder support
Disassembly and Assembly
Unscrew cylinder cap no. 11 using the O.P.A.S.
cylinder nut wrench (P/N 529 035 840).
529035840
4
F18K0NA
2
1
3
1. Cylinder cap
2. Cylinder support
3. Pivot rod
4. O.P.A.S. cylinder nut wrench
Remove cylinder assembly out of cylinder sup-
port.
GTX Series, Wake and RXT Models
1
F18K1DA
3245
1. Pivot rod
2. Spacer
3. Cylinder cap
4. Piston
5. Spring
Discard the piston no. 12.Duet
o the presence of
split rings around the pisto
n, it must be replaced
each time when removed for
proper cylinder func-
tionality.
244 smr2005-039
