MRD 3187B - User Manual
Page 164 (245)
4.23 Event Log
Description: The MRD 3187B has user selectable event logging that it stores to a
list. The list includes the date and time of each event, a short description of the
event, and which card was affected by the event. To configure the MRD 3187B to
log specific events from a predefined list, use the steps below.
Event Log
To setup and display the current errors on the unit use the following steps:
1. Press the
button.
2. Use the
and
buttons to move the
cursor to “Event Log,” then press the
button to enter the “event Log Menu.”
Event Logging Setup
Note: The Event Log List is dependent on the installed options.
To setup which events will log into the Event Log, follow the steps below:
1. Use the
and
buttons to move
the cursor to “Event Logging Setup,”
then press the
button.
2. Use the
and
buttons to select
which event to turn enable or disable,
then press the
button.
3. Select either “On” or “Off”, then press
the
button.
Event Log Display
To display the current errors on the unit use the following steps:
1. Use the
and
buttons to move
the cursor to “Event Log”, then press
the
button to choose which day to
view.
2. Use the
and
buttons to move
the cursor to choose either “current”,
“day 1 log”, “day 2 log” or “day 3 log”,
then press the
button.
3. Use the
and
buttons to move
the cursor to “display” and press the
button.
Event Log
►current
day 1 log
day 2 log
Event Log Menu
Event Logging Setup
►Event Log
Event Log List
►Vid Not Decode:On
Vid Type:On
Vid Unknown:On
Event Log Menu
►Event Logging Setup
Event Log
Menu
►Event Log
Splice Requests
Pwd Strength
To Next Page
