Sencore MRD 3187B - MPEG2 Decoder 4:2:2 with Genlock (1 Video, 4 Audio) - Option 8733

MRD 3187B - User Manual
Page 154 (245)
4.21 MPEG2 Decoder 4:2:2 with Genlock (1 Video, 4 Audio) –
Option 8733
General Information
Install Location: Not Field Upgradeable
I/O: The input is done through the various other input option cards (e.g. 8701A). The
output is done through the 8712 output option.
Supported Formats: Option 8733 can decode MPEG-2 4.2.2, and the formats
supported by the 8712 option card.
Description: With the 8733 decoder board the MRD 3187B can only be configured
as a Single RDS. Meaning only one MPEG Decoder. The MRD 3187B with the
8733 decoder board can be configured to process four audio streams.
Decoder Setup
To setup the MRD 3187B to be able to decode the incoming audio and video use the
following steps.
1. Press the button to bring the display back to the RDS status screen.
2. Press the or button to access the Decoder Menu.
Note: With this Decoder card (8733) the MRD 3187B can only have one decoder so
either of the or buttons will display the same decoder menu.
3. Use the and buttons to move the
cursor to “Service Setup”, then press the
button. The Service Setup status will
be displayed.
4. Press the button again to display the
Edit screen for the Service Setup.
Tune Mode
1. Use the and buttons to move the
cursor to “Tune Mode:” then press the
button.
2. Use the and buttons to select
the desired mode (“Auto”, “No PSI”, “PID
Lock”, “Priority”), then press the
button to save the selection.
PID Lock Mode
This mode is the most desirable and will produce the most consistent output. If
possible this mode should always be used.
Serv Setup
►Tune Mode:Pid Lock
PID Select:Manual
PCR PID :0x0000
RDS 1 ←→
►Service Setup
Sdi Aud Embed
Video Status
