MRD 3187B - User Manual
Page 186 (245)
5.1 Login
To login to the remote web client for the MRD 3187B, use the following steps:
1. Open an Internet Explorer browser window
or a Firefox browser window, then type the
IP address of the MRD 3187B into the
address box and press ENTER.
Note: The IP address of the MRD 3187B can be found from the front panel “Network
Setup” settings, see Section 4.26.
2. Select either the “admin (read-write)” or
“user (read-only)” Username, and enter the
associated password. Press the
button to log into the MRD.
Note: By default there is no password.
Note: If the password was changed (see Section 5.6) it can be recorded in the provided
space below.
Password:__________________________
5.2 Status Indicators
Once logged into the web client, there are many things to take note of. The first things
are the four status indicators along the top of the screen.
These indicators directly reflect the two status LEDs on the front panel. A green LED
means the status of that object is good and a red LED means that status of that object is
in error. If any of the indicators are red, a more detailed explanation is provided by
clicking on the tab and looking under the first section, “Error List.”
Refer to Appendix B for a more detailed explanation of the individual errors.
5.3 Configuration
When setting up the MRD 3187B using the web client, some of the same things apply as
the front panel. In a Configuration 2 unit, RDS1 and RDS2 are differentiated in the first
two tabs. To setup the Input, Services, and Output use the steps in the following
sections.
