Appendix C.c. Serial TS Input/Output (DVB-ASI /SMPTE 310M) – Option
8702
General -
Configuration:
ASI or 310M, selectable (Not simultaneously)
Connector:
(2) BNC, female
Impedance:
75 ohms
ASI Serial TS Input / Output -
Number of ASI Inputs:
1
Number of ASI Outputs:
1 (non loop-through)
Standard:
EN50083-9 (V2:3/98) DVB ASI
Data Bit Rate:
270 Mbps
Max TS Rate Supported:
160 Mbps (Dependent on configuration)
310M Serial TS Input / Output -
Number of 310M Inputs:
1
Number of 310M Outputs:
1 (non loop-through)
Standard:
SMPTE 310M
Data Bit Rate:
19.39 Mbps, synchronous
Appendix C.d. High Bit Rate ASI Input – Option 8703
This card is not needed with 8730A/8732 decoder, but is supported in the MRD 3187B.
ASI Serial TS Input / Output –
Number of ASI Inputs:
1
Number of ASI Outputs:
1 (passive loop-through)
Standard:
EN50083-9 (V2:3/98) DVB ASI
Max Program Bit Rate:
54 Mbps
Data Bit Rate:
270 Mbps
Max TS Rate Supported:
160 Mbps for MPTS
Connector:
(2) BNC, female
Impedance:
75 ohms
