MRD 3187B - User Manual
Page 150 (245)
3. Use the and buttons to move
the cursor to “Audio4 Typ:” then press
the button.
4. Use the and buttons to
select the audio type (“Dolby AC3”,
“AAC ADTS”, “AAC LOAS”, “Dolby D
+”, “MPEG 1”, “MPEG 2”) on the PID
chosen above, then press the
button.
DolbyE 1
Note: This option is only available if there is an 8707A audio output card
installed.
1. Use the and buttons to move
the cursor to “DlbyE1 PID:” then press
the button.
2. Use the and buttons to
select the column to edit and use the
and buttons to set the Dolby
E1 PID, then press the button to
save the selection.
Auto Mode
This mode should only be used if no PID information is known about the stream.
Auto Program
Note: This menu is only available if the “Tune Mode” is set to “Auto”.
1. Use the and buttons to move
the cursor to “Auto” then press the
button.
2. Use the and buttons to
select the desired Service number in
the stream, then press the button
to save the selection.
SDI Audio Embedding
SDI Audio Embedding places decoded or pass through audio in the video horizontal
space in one of 4 available locations. The 4 locations are Group 1 – pair 1 and pair 2,
and Group 2 pair 1 and 2. If there is an 8707A audio output card installed, then
DolbyE audio can be embedded. To setup the assignment audio to one of the SDI
audio embedding locations, use the following steps:
1. Start out at the home screen (where it
shows the TS bit rate).
2. Press the
button.
3. Use the
and
buttons to move the
cursor to “Sdi Aud Embed”, then press the
button.
RDS 1 ←→
Service Setup
►Sdi Aud Embed
Video Status
Serv Setup
Tune Mode:Auto
►Service:
-
Serv Setup ←→
Aud 2 PID:0x0024
Audio2 Typ:AAC ADTS
►DlbyE1 PID:0x0000
Serv Setup ←→
Aud 4 PID:0x0024
►Audio4 Typ:Dolby D +
DlbyE1 PID:0x0000
