MRD 3187B - User Manual
Page 193 (245)
The ATSC table grouping includes displaying
the MGT, TVCT, EIT or STT. Click the tabs
at the top of the window to view the
corresponding table.
The DVB table grouping displays the SDT.
The PSIP Table display window can be
resized to fit the table being displayed. Scroll
bars allow displaying the parts of the table
that do not fit in the window.
The displayed table is not automatically
updated if the content changes. Use the
button to update the table
display. Changing tables will also display the
current table information.
In order to close the PSIP table display
window, use the or button.
5.4 Unit
This section will describe what information is included under the tab.
5.4.1 Active Errors
The first thing under this tab is the “Active
Errors.” If any of the status indicators across
the top of the web client are indicating an
error (i.e. red circle) this section will give a
more detailed description of the specific error
along with the location of the item that is
producing the error.
5.4.2 Event Logging
Just below the “Active Errors” is the “Event Logging” section. This section shows all
the possible events that the MRD 3187B will log. Follow the steps below to either
enable or disable an event.
