Appendix C.i. Dual Video Output (2 SDI, 1 RGBHV/YPbPr/Composite) –
Option 8708
General –
Connector:
2 Female BNC
Impedance:
75 ohms ±10%
Output Connectors:
2 – SDI, 1 – RGBHV/YPbPr/Composite
(Composite/YPbPr output with breakout cable only)
Genlock –
SDI:
Line and Pixel Adjustment
Composite:
Line, Pixel, Color Phase Adjustment
SDI (Serial Digital Interface) Video Out
–
HD-SDI Standard:
SMPTE 292M
SMPTE 274M (1080i and 1080p)
SMPTE 296M (720p)
SD-SDI Standard:
ITU-BT.601/SMPTE S259M
Data Bit Rate:
SD-SDI = 270 Mbps
HD-SDI – 1.485 Gbps
Display Modes:
HD: Pillarbars, Cropped, Anamorphic
SD: Letterbox, Cropped, Anamorphic
Embedded Audio Format:
SD-SDI – SMPTE 272M
HD-SDI – SMPTE 299M
Sample Rates Supported:
48 kHz
Sample Rate Out:
48 kHz
Output Squelch:
Selectable – Enable/Disable (when no input is
detected, output is muted)
Number of Embedded Audio
Channel Pairs:
4 (2 groups, each with 2 pairs)
Audio Types Supported:
AC-3, MPEG-2 layer 1 and 2, or PCM
DolbyE (with 8707A)
Embedded Audio Control:
Selectable – “type”/disable (each pair independently
controlled)
Audio Type Standard:
Compressed (IEC 60958)
Uncompressed (IEC 61937)
Closed Captions:
Embedded – EIA-708B or EIA-608B
Line 21 – Enabled/Disabled (selectable) SDI and
Composite controlled simultaneously
Analog Video -
Video Format Standards:
SMPTE 274M (1080i and 1080p)
SMPTE 296M (720p)
SMPTE 253M (480p, 480i)
(reference EIA 770.2 and 770.3)
Number of Analog Outputs:
1 (shared: RGBHV or YPbPr/Composite via breakout
cable)
Connector:
High Density 15-pin D-sub, female
Impedance:
75 ohms, ±10%, 1 Kohm for syncs
Return Loss:
>20 dB, 30 kHz – 30 MHz
Frequency Response:
Y = 30 kHz – 30 MHz, ± 0.2 dB ripple
PbPr = 30 kHz – 15 MHz, ± 0.2 dB ripple
H/V Sync:
4 Vpp into 1 Mohm, positive polarity
Options available –
8708 Opt 1:
Analog video breakout cable
Connectors:
(5) BNC, male:
R, G, B, Horizontal Sync, Vertical Sync, Pr, Y, Pb, -
-, Composite
(1) High density 15-pin D-sub, female
Length:
48 inches
