Appendix C.g. Video Output (1 RGBHV/YPbPr, 1 Composite) – Option 8706A
Analog Video General -
Video Standards:
SMPTE 274M (1080i and 1080p)
SMPTE 296M (720p)
SMPTE 253M (480p)
SMPTE 170M (480i)
(Reference: EIA 770.2 and 770.3)
Output Formats:
1920 x 1080 Interlaced (1080i)
1920 x 1080 Progressive (1080p)
1280 x 720 Progressive (720p)
720 x 480 Progressive (480p)
720 x 480 Interlaced (480i)
Frame Rates:
1080i@ 25 Hz, 29.97 Hz, 30 Hz
720p@ 50 Hz, 59.94 Hz, 60 Hz
480p@ 59.94 Hz
480i@ 29.97 Hz
Aspect Ratio:
16x9 (fixed: 1080i, 720p)
16x9, 4x3 (selectable: 480p, 480i)
Display Modes:
HD: Letterbox, Cropped, Anamorphic
SD: Letterbox, Cropped, Anamorphic
Composite General –
Standard:
ANSI/SMPTE 170M-1994
CCIR656
PAL Standard
Output Formats:
NTSC:
480 Interlaced
PAL:
576 Interlaced
Note: Simultaneous RGB/YPbPr and Composite operation in 480i, 29.97 Hz format only.
Analog Video –
Number of Outputs:
1 (shared: RGBHV and YPbPr)
Connector:
High Density 15-pin D-sub, female
Impedance:
75 ohms, +/-10%; 1 k ohm for syncs
Return Loss:
>20 dB, 30 KHz – 30 MHz
Frequency Response:
Y = 30 KHz – 30 MHz, +/-0.2 dB ripple
PbPr = 30 KHz – 15 MHz, +/-0.2 dB ripple
H/V Sync:
4 Vpp into 1 Mohm, negative polarity
Composite Video Out –
Number of Outputs:
1 (NTSC/PAL)
Connector:
BNC, female
Impedance:
75 ohms, +/-10%
Return Loss:
>25 dB
Frequency Response:
DC to 6.0 MHz
Amplitude:
140 IRE (1.0 Vpp), +/-2 IRE
NTSC -
Standard:
ANSI/SMPTE 170M-1994; CCIR656
Format, Frame rate
525 lines, 29.97 Hz (480i)
Setup (pedestal):
On/Off, selectable
Closed Caption:
Enable/Disable, selectable
CC Standard:
EIA-608B
PAL -
Standard:
ITU-R.BT.470-6
Format, Frame rate: 625 lines, 25.00 Hz
Genlock -
Line and Pixel Adjustment
Color Phase Adjustment (8706A Only)
