Appendix C.f. Video Output (2 HD-SDI, 1 RGBHV/YPbPr) – Option
8705/8705A
General -
Output Connectors:
2 – HD-SDI, 1 – Analog Video
Output Formats:
1920 x 1080 Interlaced (1080i)
1280 x 720 Progressive
720 x 480 Progressive (480p)
720 x 480 Interlaced (480i)
Frame Rates:
1080i@ 25 Hz, 29.97 Hz, 30 Hz
720p@ 50 Hz, 59.94 Hz, 60 Hz
480p@ 59.94 Hz
480i@ 29.97 Hz
Aspect Ratio:
16x9 (fixed: 1080i, 720p)
16x9, 4x3 (selectable: 480p, 480i)
Display Modes:
HD: Letterbox, Cropped
SD: Letterbox, Cropped
HD-SDI –
Standard:
SMPTE 292M
Data Bit Rate:
1.485 Gbps
Number of Serial Outputs:
2
Connector:
(2) BNC, female
Impedance:
75 ohms, +/-10%
Return loss:
≥15 dB,
Number of Video formats Supported:
2
Video Format Standards:
SMPTE 274M (1080I, 29.97 Hz)
SMPTE 296M (720P, 59.94 Hz)
Embedded Audio Format:
SMPTE 299M
Sample Rates Supported:
32, 44.1, 48 KHz
Sample Rate Output:
48 KHz
Number of Embedded Audio Channel
Pairs:
4 (2 groups, each with 2 pairs)
Audio Types Supported:
AC3, MPEG2 layer 1 and 2, or PCM
DolbyE (With 8707A)
Embedded Audio Control:
Selectable – “type” and disable
(Each pair independently controlled)
Audio Type Standard:
Compressed (IEC 60958)
Uncompressed (IEC 61937)
Closed Captions:
Embedded - EIA-708B or EIA-608B
Enable/Disable – selectable
Analog Video –
Video Format Standards:
SMPTE 274M (1080i)
SMPTE 296M (720p)
SMPTE 253M (480p, 480i)
(Reference: EIA 770.2 and 770.3)
Number of Analog Outputs:
1 (shared: RGBHV and YPbPr)
Connector:
High Density 15-pin D-sub, female
Impedance:
75 ohms, +/-10%, 1 Kohm for syncs
Return Loss:
>20 dB, 30 KHz – 30 MHz
Frequency Response:
Y = 30 KHz – 30 MHz, +/-0.2 dB ripple
PbPr = 30 KHz – 15 MHz, +/-0.2 dB ripple
H/V Sync:
4 Vpp into 1 M ohm, positive polarity
Genlock -
HD-SDI:
Line and Pixel Adjustment
