Appendix C.t. PID Filtering Dual MPEG over IP UDP Output – Option 8728
General –
Connector:
2 – 10/100/1000 Auto-negotiating Base-T
RJ-45 Ethernet Port
Card Latency:
Transmit –
≤1000ms
Output Format:
UDP
Bitrate Range:
1 – 160 Mbps per TS (constant bit rate)
400 Mbps Aggregate
Packets/IP Frame:
1-7 MPEG Packets/IP Frame
Number of Outputs:
PID Filtering –
PCR:
Table Manipulation:
5 Independent TS (MPTS or SPTS), each routed to
one of two Ethernet ports as desired – Unicast
and/or Multicast
PCR restamping
Automatic table adjustment
In MPEG mode:
Adjusted tables: PAT, PMT
Pass through tables: CAT, NIT
Discarded tables: all remaining tables
In DVB mode:
Adjusted tables: PAT, PMT, SDT actual
Pass through tables: CAT, NIT, BAT, etc
Discarded table: TSDT
