Sencore MRD 3187B - Section 3 - Option Cards Overview

MRD 3187B - User Manual
Page 18 (245)
Section 3 – Option Cards
Overview
Introduction
This section includes a brief overview of the different option cards that are available
for the MRD 3187B. There are descriptions of each card as well as pictures of the
various inputs and outputs for each card.
3.1 8VSB/QAM Receiver – Option 8701A ....................................................................... 21
3.2 Serial Transport Stream I/O (DVB-ASI/SMPTE 310M) – Option 8702...................... 21
3.3 High Bit Rate ASI Input – Option 8703 ...................................................................... 21
3.4 Video Output (2 SD-SDI, 1 Composite) – Option 8704A/8704B ............................... 21
3.5 Video Output (2 HD-SDI, 1 RGBHV/YPbPr) – Option 8705/8705A .......................... 21
3.6 Video Output (1 RGBHV/YPbPr, 1 Composite) – Option 8706A ............................... 21
3.7 Audio Output (Dolby E, AES Digital, Analog) – Option 8707A .................................. 21
3.8 Video Output (2 HD/SD-SDI, 1 RGBHV/YPbPr/Composite) – Option 8708 ............. 22
3.9 Dual Input DVB-S/DVB-S2 Receiver – Option 8710/8710A ...................................... 22
3.10 Dual Input ASM Receiver – Option 8711 ................................................................... 22
3.11 Video Output (2 HD/SD-SDI, 1 RGBHV/YPbPr/Comp) – Option 8712 ..................... 22
3.12 GPIO Module – Option 8713 ..................................................................................... 22
3.13 Dual Input COFDM Receiver – Option 8715 ............................................................. 22
3.14 Quad Input DVB-S/DVB-S2 with LNB – Option 8716/8716G .................................... 23
3.15 CAM Decryption – Option 8721 ................................................................................. 23
3.16 Backup Network Controller – Option 8724 ................................................................ 23
3.17 MPEG over IP Input/Output – Option 8725 ............................................................... 23
3.18 Dual MPEG over IP Input/ UDP Output – Option 8727 ............................................. 23
3.19 PID Filtering Dual Output MPEG over IP UDP Output– Option 8728 ....................... 24
3.20 License Options ......................................................................................................... 24
