Appendix C.h. Audio Output (DolbyE, AES Digital, Analog) – Option 8707A
General –
Audio Source:
Selected Audio Services 1-4
# Of Services:
2 supported per 8707 option card
Service Source:
MRD Configuration 1 Opt 1/3 (2 services)
MRD Configuration 1 Opt 2/4 (4 services)
(Requires 2 - 8707 cards)
Modes:
User defined, Monitor, Transmission
DolbyE PID:
DolbyE extracted digital data output provides
extracted DolbyE for embedding
Digital Audio Out –
DolbyE:
Available with breakout cable on 15-pin D-sub
Connector
Digital Output format:
S/PDIF/AES3id (Unbalanced)
Type (selectable):
Raw (native – AC3, MPEG, etc.),
PCM (uncompressed Ch1 and 2),
Standard:
IEC 60958-3 AC-3 (consumer),
MPEG-1/2, layers 1 and 2
AES3id (IEC 60958-4/61937), Ch1/2
(professional)
Connector:
(2) BNC, female
Impedance:
75 ohms
Analog Audio Out -
Output Type:
Balanced, 2 channel pairs (+/-, L/R)
Source:
Same as selected Digital PCM above
Conditions:
Load=600 ohms,
–20 dBFS encoded TS source
Amplitude:
24.4 dBu
Adjustable down to 4 dBu
Max Output:
27 dBu
THD+N:
<0.01%
Crosstalk:
<-85 dB
Frequency Response:
20 Hz to 20 KHz < +/-0.1 dBu
Connector:
High density 15-pin D-sub, male
Impedance:
600 ohms nominal
50 ohms min.
Options available –
8707A Opt 1:
Audio breakout cable with XLR and DolbyE BNC
Connectors:
(4) XLR, male; Chan 1 – L,R Chan 2 – L,R
(1) BNC, male; DolbyE
(1) High density 15-pin D-sub, female
Length:
14 inches
8707A Opt 3:
Audio breakout cable with unbalanced BNC and
DolbyE BNC
Connectors:
(5) BNC, male; Chan 1 – L,R Chan 2 – L, R
DolbyE
(1) High density 15-pin D-sub, female
Length:
14 inches
8707A Opt 4:
DolbyE breakout cable
Connectors:
(1) BNC, male; DolbyE
(1) High density 15-pin D-sub, female
Length:
14 inches
