Sencore MRD 3187B - Appendix C - Specifications; Appendix C.a. MRD 3187 B - Base Unit

MRD 3187B - User Manual
Specifications are subject to change without notice.
Page 211 (245)
Appendix C – Specifications
Appendix C.a. MRD 3187B – base unit
Includes:
Display, keypad, embedded controller, Chassis/case,
Power Supply/line cord
System –
Display type:
VFD (Vacuum Fluorescent Display)
Display Configuration:
4 lines x 20 characters
Keypad:
Membrane switches
Front Panel Lockout:
Password control, up to 10 alpha-numeric characters
(no punctuations or spaces allowed
Configurations Allowed:
Single RDS – 8-Slot (Configuration 1)
Dual RDS – 4-Slot each RDS (Configuration 2)
Rear panel:
Eight available slots
Six I/O interface slots
Two video output slots
(Configuration dependent)
Remote Operation/Update Interface –
Type:
Ethernet, 10/100
Rear panel indicators:
Link (Green LED), Activity (Amber LED)
Connector:
RJ45
Serial Remote operation interface –
Type:
RS232
Protocol:
115, 8, N, 1
Connector:
9-pin D-sub, male
Front Panel Indicators –
Input LED:
Green indicates valid input on selected input
Off indicated no valid signal on the selected input
Constant Blinking Green for Configuration 2 units
indicates one valid input and one invalid input
Error LED:
Red indicates error is occurring
Off indicated no errors detected
AC Power –
Operating Voltage:
95–135 VAC or 180–265 VAC
Max Power:
200 W
Current Draw/Power:
Typical 1 Decoder with 4 option
cards:
0.40 A / 50 W
Typical 2 Decoders with 8 option
cards:
0.60 A / 70 W
Frequency:
47–63 Hz
Connector:
IEC C14
Line Cord:
Detachable, 6 foot, 3-prong
DC Power –
Operating Voltage:
40 – 60 VDC
Max Current Draw/Power:
4.17 A / 200 W (at 48 VDC)
Current Draw/Power:
Typical 1 Decoder with 4 option
cards:
1.04 A / 50 W
Typical 2 Decoders with 8 option
cards:
1.46 A / 70 W
Connector:
Tyco Amplimite 109 series 3C3
Line Cord:
Detachable, 5 ½ foot
