4.26 Network Setup
Description: The MRD 3187B can be setup on a network connection to allow remote
management and SNMP configuration. For these features to work, the network
settings for the MRD 3187B must first be configured properly for the network it is
connected to.
Static IP Address
To setup the MRD 3187B with a static IP address, use the following steps:
1. Press the button.
2. Use the and buttons to move the
cursor to “Network Interface”, then press
the button.
Note: The following menu will be
present only if the 8724 Backup
Network Controller is installed.
1. Use the and buttons to
move the cursor to “Set Default Gw
Port”, then press the button.
2. Use the and buttons to
move the cursor to “Default Gw:”, then
press the button.
3. Use the and buttons to
change the selection to, “Ctrl 1” or “Ctrl
2”, then press the button to save
the selection.
4. Use the and buttons to
move the cursor to “Control 1” or
“Control 2”, then press the button.
3. Use the and buttons to move the
cursor to “DHCP:” then press the
button.
4. Use the and buttons to change
the selection to, “off”, then press the
button to save the selection.
Network
►Dhcp:off
IP Address
0.0.0.0
Network Select
►Control 1
Control 2
Set Default Gw Port
Network Gateway
►Default Gw:Ctrl 1
Network Select
Control 1
Control 2
►Set Default Gw Port
Menu
Network Services
►Network Interface
Lock Panel
