Appendix C.y. MPEG-2/MPEG-4 Decoder (1 Video, 2 Audio) – Option 8734
General –
TS Data Rate:
1-160 Mb/s
Video Decoder –
Compatibility Standard:
MPEG-2 4:2:0 MP@HL & MP@ML
MPEG-4 H.264 Compatible MP@4.1 & HP@4
Video Bit Rate:
MPEG-2 1-80 Mbps (dependent on profile)
MPEG-4 H.264 1-50 Mbps (dependent on profile)
Primary Video Formats:
1080i@ 25 Hz, 29.97 Hz, 30 Hz
720p@ 50 Hz, 59.94 Hz, 60 Hz
480p@ 59.94 Hz
480i@ 29.97 Hz
576i@ 25 Hz
Format Scaling:
Output Format Selectable
Display Modes:
Letterbox, Cropped, & Anamorphic
Aspect Ratio:
16x9, 4x3 (Selectable - format dependent)
Audio Decoder –
Output Formats:
IEC-60958 (uncompressed)
IEC-61937 (compressed)
PCM Downmix
Allowed MPEG-2 PES Formats:
MPEG-2
MPEG-1
AC-3
EAC-3
MPEG-2 AAC ADTS
MPEG-4 AAC ADTS & LOAS
HE-AACv1
HE-AACv2
All pass-through compatible
Service Source:
MRD Configuration 1 Opt 1/3 (2 services)
PCM Downmix (selectable):
L/R (Stereo), Lt/Rt (Surround), Auto, Mono1, Mono2
Modes (selectable):
User defined, Monitor, Transmission
AV Lip-sync -
Includes control for audio PTS and PCR tracing
Genlock Capability -
Includes Genlock capability for 8704A, 8705 video output
card.
Limited support for earlier 8704 and 8706 video output card
(No Color burst phase adjust on NTSC outputs)
HD – Adjustment of pixels and lines. Max number
dependent on video mode
SD – Adjustment of Color burst phase, pixels, and lines.
Genlock Reference -
Video 1080i @ 25 fps
– Ref 1080i tri-level sync @ 25 fps
– Ref NTSC “black and burst”
Video 1080i @ 29.97
– Ref 1080i tri-level sync @ 29.97 fps
Video 1080i @ 30 fps
– Ref NTSC 1080i tri-level sync @ 30 fps
Video 720p @ 50 fps
– Ref 720p tri-level sync @ 50 fps
– Ref 720p tri-level sync @ 25 fps
Video 720p @ 59.94
fps
– Ref 720p tri-level sync @ 59.94 fps
– Ref 720p tri-level sync @ 29.97 fps
– Ref NTSC “black and burst”
Video 720p @ 60 fps
– Ref 720p tri-level sync @ 60 fps
– Ref 720p tri-level sync @ 30 fps
Video 480i @ 29.97
– Ref NTSC “black and burst”
Note: AC-3 is a registered trademark of Dolby Laboratories
