MRD 3187B - User Manual
Specifications are subject to change without notice.
Page 224 (245)
Video Output (2 SDI, 1 RGBHV/YPbPr/Composite) – Option 8712
(continued)
Composite Video Out –
Number of Outputs:
1 (NTSC/PAL)
Connector:
Breakout cable into BNC, female
Impedance:
75 ohms, +/-10%
Return Loss:
>25 dB
Frequency Response:
DC to 6.0 MHz
Amplitude:
140 IRE (1.0 Vpp), +/-2 IRE
Display Modes:
Letterbox, cropped, anamorphic
NTSC
PAL
Standard:
ANSI/SMPTE 170M-1994;
CCIR656
ITU.R.BT.470-6
Format, Frame
rate:
525 lines, 29.97 Hz
(Interlaced)
625 lines, 25.00 Hz (Interlaced)
Setup (pedestal):
On/Off, selectable
Closed Caption:
Enable/Disable, selectable
CC Standard:
EIA-608B
