CDHD Specificat ions
User Manual 25
Sin g le and Thre e
Phase 1 2 0/ 2 4 0 VAC
Spe cifica t ion CD H D - 0 0 8 CD H D - 0 1 0
CD H D -
0 1 3 * *
Pow e r Te m pe r a t u r e
Fan
Norm ally operates at quarter power;
when tem perature exceeds high-speed
fan trigger tem perat ure, operates at full
power
Yes Yes Yes
Power Module Over-Temperatu re Fault
Regulated (° C)
80 ± 5% 80 ± 5% 80 ± 5%
Power Module Over-Temperatu re Fault
Non-regulated ( ° C)
100 ± 5% 100 ± 5% 100 ± 5%
Power Module Over-Temperatu re Fault
(° C)
100 100 100
Trigger Tem perature for High Speed Fan
(° C)
45 45 45
Ex t e rnal Regene ra t ive
Resist or ( B1 + , B2 )
External regenerative
resistor requirement
(regen resist or not
supplied with drive)
Peak current ( A) 40 40 40
Minimum resistance (Ω) 10 10 10
Power Rating (W)
Syst em -
dependent
Syst em -
dependent
Syst em -
dependent
Application Inform ation Internal Bus Capacitance ( µF) 2110 2110 2110
VLOW ( Regen Circuit Turn Off) (VDC) 380 380 380
VMAX (Regen Circuit Turn On) (VDC) 400 400 400
* Line to Line: L1 to L2, or L1 to L3 or L2 to L3
* * 3-Phase only
Ta ble 3 - 4 . Me cha n ica l & Elect rica l Specifica t ions –
CD H D - 0 2 0 / CD H D - 0 2 4 ( 1 2 0 / 2 4 0 VAC)
Three- Phase
1 2 0 - 2 4 0 VAC
Spe cifica t ion CD H D - 0 2 0 CD H D - 0 2 4
Ra tings
Input Power Circuit
(L1, L2, L3)
Voltage (VAC Line- Line* ) Nom inal ± 10% 120/ 240 120/ 240
Line Frequency (Hz) 50/ 60 50/ 60
120/ 240 VAC 3 Phase 3 Phase
Continuous Current (3 ph A rms) 20@240V 24@240V
Line Fuses (FRN-R, LPN, or equivalent) (A) 25 30
Withstand Voltage ( Primary to Earth)
1500 VAC
(2121 VDC)
1500 VAC
(2121 VDC)
Control Circuit Input
Power (L1C, L2C)
120 or 240 VAC 1 Phase 1 Phase
Logic Input Fuse
(Time Delay)
120 or 240 VAC (A) 0.5 0.5
STO (Safe Torque Off) STO Power supply (VDC) 24 ± 5% 24 ± 5%
STO Fuse (Tim e Delay) 24 VDC ± 10% 1.5 1.5
