Specificat ions CDHD
24 User Manual
Ta ble 3 - 3 . M e ch a n ical & Ele ctrical Spe cificat ions –
CDH D - 0 0 8 / CD H D - 0 1 0 / CD HD - 0 1 3 ( 12 0 / 2 4 0 VAC)
Sin g le and Thre e
Phase 1 2 0/ 2 4 0 VAC
Spe cifica t ion CD H D - 0 0 8 CD H D - 0 1 0
CD H D -
0 1 3 * *
Ra tings
Input Power Circuit
(L1, L2, L3)
Voltage (VAC Line- Line* ) Nominal
± 10%
120/ 240 120/ 240 120/ 240
Line Frequency (Hz) 50/ 60 50/ 60 50/ 60
120/ 240 VAC 1/ 3 Phase 1/ 3 Phase 3 Phase
Continuous Current (3 ph A rm s) 5 8 10
Line Fuses ( FRN- R, LPN, or equivalent) 10 10 15
Withstand Voltage (Prim ary t o Earth)
1500 VAC
(2121 VDC)
1500 VAC
(2121 VDC)
1500 VAC
(2121 VDC)
Control Circuit Input
Power (L1C, L2C)
120 ± 10 or 240 ± 10 VAC 1 Phase 1 Phase 1 Phase
Logic Input Fuse
(Time Delay)
120 or 240 VAC (A) 0.5 0.5 0.5
STO (Safe Torque Off) STO Power supply (VDC) 24 ± 10% 24 ± 10% 24 ± 10%
STO Fuse (Tim e Delay) 120 or 240 VAC (A) 1.5 1.5 1.5
Mot or Output ( U, V, W) Continuous Output Current (A rms) 8 10 13
Continuous Output Current ( A peak) 11.31 14.14 18.38
Peak Output Current (A rms) for
2 seconds
28 28 28
Peak Output Current (A peak) for
2 seconds
39.56 39.56 39.56
kVA at 120 VAC 1.1 1.3 1.7
kVA at 240 VAC 1.7 2.2 2.8
PWM Frequency (kHz) 8 8 8
Soft Start Max. Surge Soft Start Current (A) 15 15 15
Max. Charge Time (m s) 350 350 350
Power Circuit Loss W
Control Circuit Loss W 5 5 5
Total Power Loss W
H ar d w a r e
Unit Weight kg 1.15 1.15 1.15
Connection Hardware PE Ground Screw Size/ Torque M4/ 1.35 Nm M4/ 1.35 Nm M4/ 1.35 Nm
Wire Size Control Circuit (AWG) up to 3 meters 24-28 24- 28 24- 28
Main Circuit Mot or Lines (AWG) 14 14 14
Main Circuit AC Inputs (AWG) 14 14 14
PE Ground Screw M4 M4 M4
Clearance Dist ance Side- to-Side (mm) 15 15 15
Top/ Bottom (m m) 50 50 50
Volt a g e Trip
Under-Voltage Trip (nom inal) (VDC) 100 100 100
Over-Voltage Trip (VDC) 420 420 420
