CDHD Diagnostics and Troubleshooting
User Manual 261
L2 H ardw are Ne gat ive Lim it Sw itch is Open
L2 Displayed in sequence
D e finit ion Hardware Negative Lim it Switch is Open
Type Warning
Act ive disa ble Not Applicable
M e ssage # WRN 16
Descr iption Negative hardware limit switch is activated.
Action required
L3 H ardw are Posit ive and Ne ga tive Lim it Sw it ches are Open
L3 Displayed in sequence
D e finit ion Hardware Posit ive and Negative Limit Switches are Open
Type Warning
Act ive disa ble Not Applicable
M e ssage # WRN 17
Descr iption
Positive and negative hardware limit switches are both
act ivated.
Action required
L4 Softw a re Posit ive Lim it Sw itch is Tripped
L4 Displayed in sequence
D e finit ion Soft ware Posit ive Limit swItch is Tripped
Type Warning
Act ive disa ble Not Applicable
M e ssage # WRN 18
Descr iption
Positive soft ware lim it switch is activated.
PFB > POSLI MPOS and
POSLI MMODE = 1
Action required
