SICK FLOWSIC100 User Manual

Assembly and Installation
FLOWSIC100 · Operating Instructions · 8012513/YSA5/V2-1/2016-07 · © SICK Engineering GmbH 103
Subject to change without notice
Fig. 74 FLOWSIC100 PR connection on the MCU
24 V
1
2
3
4
5
6
RS485
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
+24 V DC
GND
a-unit A b-unit A
+24 V DC GND a-unit A b-unit A
MCU
FLSE100-PR
Connection cable, Slave
(length 5/10/50 m)
Plug-in connectors
Junction box (optional)
Onsite cable
Processor board
WH BN GN YE
G
F
A Operation/malfunction
B Maintenance
C Check cycle
D Maintenance
E Limit values
FOnsite cable to second junction box
For bus cabling (two-path measurement), version B
G Cable provided by customer to second junction box
For bus cabling (two-path measurement), version A
A
BCD
E
Plug-in connector assign-
ment, Slave: Outer view
RS485 to Master
43
61
BN WH
GN YE
BL
GN
YE
WH
BN
GN
YE
WH
BN
GN
YE
WH
BN
