EVERY 10 HOURS
Telescopic arm
Greasing of the arm support pin See par. “6.11.1” pag. 136
Greasing the jack pins for arm lifting See par. “6.11.2” pag. 137
Checking and greasing the telescopic extension
and rollers
See par. “6.11.6” pag. 141
Greasing of arm total rotation pins and rotation
jack pins
See par. “6.11.3” pag. 138
Greasing of the vibrating head oscillation jack
pins
See par. “6.11.4” pag. 139
EVERY 50 HOURS
Wheels
Check all bolts and nuts See par. “6.8.3” pag. 124
Tire pressure check See par. “6.8.4” pag. 124
Vibrating head
Checking the state of wear on bands and rubber
pillows
See par. “6.10.8” pag. 133
See par. “6.10.9” pag. 134
Check all bolts and nuts See par. “6.10.6” pag. 132
EVERY 150 HOURS
Complete machine
Checking the state of wear and efficiency of the
chrome plated jack rods
-
Electrical system Electric cables position check See par. “6.9.2” pag. 125
Hydraulic system
Hydraulic system efficiency check -
Check and reset hydraulic oil level See par. “6.6.3” pag. 113
Checking the state of wear and efficiency of
hydraulic pipes
See par. “6.6.6” pag. 117
Vibrating head
Checking the jaws opening/closing hydraulic
cylinder
-
Telescopic arm
Wear of sliding blocks check See par. “6.11.8” pag. 143
Adjusting the play of the arm trunk guide runners -
Remove the old grease from the arm and then
grease again the sliding parts of the arm
See par. “6.11.6” pag. 141
