Machine transport and handling
• Start the tractor to which the machine is connected and align it with the
transport vehicle, positioning the rear of the machine facing the ramp.
• Make sure the PTO (540 rpm) is engaged and active.
• Operate the remote control (*).
• Act on the manipulators (3) and (4) of the remote control to lift the
machine arm and tilt the vibrating head upwards.
• Proceed as far as is necessary to avoid contact of the ramp with the
lower part of the vibrating head.
ATTENTION
When loading, pay particular attention to the lower part of the end of the
vibrating head (see Figure 26); if the operations are not carried out correctly,
there is a risk of collision between the vibrating head and the loading ramp.
3
4
ATTENTION
Before proceeding, make sure that the ramp (or the two ramps) is set up
correctly and that the machine is in the proper configuration for transport.
(*) See par. “5.6.2” pag. 96
Figure 26
57
SICMA S.r.l.
