User and maintenance manual - SEMI-MOUNTED HARVESTER WITH TRUNK SHAKER - TR80
Rev. 0 - 05/2021
• Operate the remote control (*).
• Act on the manipulators (3) and (4) of the radio control to lower the
arm of the machine and place the vibrating head on the platform of
the means of transport. If necessary, prepare a wooden stop on the
platform to support the vibrating head.
• Turn off the remote control.
• Ensure that the machine overall dimensions are within the permissible
limits.
• Stop the tractor safely by applying the parking brake and remove the
ignition keys.
• Disconnect the machine from it.
• Start the tractor to move it onto the platform and unload it.
• Carry out the procedures for anchoring the machine as indicated in
paragraph “2.1.1 Warnings for coupling/uncoupling the machine”
pag. 13.
1
2
3
4
(*) See par. “5.6.2” pag. 96
Figure 32
62
