Machine transport and handling
ATTENTION
Before proceeding with the lifting of the platform, make sure that the machine
and the tractor are correctly positioned on top of it.
If the telescopic arm extends beyond the platform at the front, there is a risk
of collision between the telescopic arm and the transport vehicle (see Figure
30).
• Engage the tractor parking break.
• Raise the platform until it is perfectly aligned with the floor of the
transport vehicle.
• Disengage the tractor parking brake to reverse, at low speed, over the
bed of the transport vehicle.
• Proceed carefully until the machine is completely positioned on the
platform.
Figure 30
Figure 31
61
SICMA S.r.l.
