User and maintenance manual - SEMI-MOUNTED HARVESTER WITH TRUNK SHAKER - TR80
Rev. 0 - 05/2021
• Drive the tractor forward at low speed, avoiding sudden movements
and accelerations.
DANGER
Do not steer on the ramp and do not operate any machine controls.
• Maintain a slow, continuous movement until the machine and the
tractor are completely unloaded from the transport vehicle.
• Act on the manipulators (3) and (4) of the radio control to bring the
telescopic arm of the machine and the vibrating head into transport
position.
• Turn off the remote control by turning the selector located on the left
side of the remote control counterclockwise (battery switch).
3
4
ATTENTION
If it is necessary to connect the machine to a different tractor from the one
used for unloading it from the means of transport, use the radio control to
position the vibrating head in advance on the ground.
Only then can the tractor be uncoupled from the machine.
Figure 36
66
