Machine transport and handling
• Operate the remote control (*).
• Act on the manipulators (3) and (4) of the remote control to lift the
machine arm and tilt the vibrating head upwards.
• Proceed as far as is necessary to avoid contact of the ramp with the
lower part of the vibrating head.
ATTENTION
During unloading, pay particular attention to the lower part of the vibrating
head (see Figure 35); if the operations are not carried out correctly, there is
a risk of collision between the vibrating head and the ramp.
3
4
(*) Vedi par. “5.6.2” pag. 96
Figure 35
65
SICMA S.r.l.
