User and maintenance manual - SEMI-MOUNTED HARVESTER WITH TRUNK SHAKER - TR80
Rev. 0 - 05/2021
ATTENTION
If the telescopic arm extends beyond the platform at the front, there is a risk
of collision between the telescopic arm and the transport vehicle (see Figure
40).
• Engage the tractor parking break.
• Lower the platform completely.
• Drive the tractor off the platform.
• Turn off the remote control by turning the special selector on the left
side of the remote control counterclockwise (battery switch).
ATTENTION
If it is necessary to connect the machine to a tractor different from the one
used to unload it from the means of transport, use the radio control to
previously position the vibrating head resting on the ground in order to allow
the machine to balance and stabilize.
Only then can the tractor be uncoupled from the machine.
Figure 40
70
