Siemens FS720 - Page 58

GUI
Cerberus Remote
5
58 | 412
Building Technologies
A6V10210424_j_en_
--
Fire Safety
2018
-
08
-
29
Cerberus-Remote is opened via the 'Cerberus-Remote' task card in the program
window.
Example of Cerberus-Remote in operation mode 'Full access (view/operation)' with
red frame
The
button with the loudspeaker symbol (bottom right in the figure) is used to
switch an activated buzzer on and off.
However it is only possible to switch the buzzer on and off on the PC and not on
the connected 'Station'.
The connection with a '
Station
' is shown by the
↑
Person Machine Interface
(display, LEDs, keys) transmitted.
The 'Cerberus-Remote access' operation mode is indicated by a red frame
around the Person Machine Interface.
An enable granted for Cerberus-Remote is retained when a 'Station' restarted.
Cerberus-Remote has the following operation modes:
● 'Limited access (view only)'
● 'Full access (view/operation)'
For both operation modes, an authorization must be configured on the ↑ 'Station'.
In addition, a ↑ license key must be installed. The license key must support the
Cerberus-Remote function.
You will find more information about license keys in document
A6V10210362
.
See chapter 'Applicable documents'.
001 AAA
001 ABC
ABC
ZZZ
ABCDEFGHI
ZZZ
ABCDEFGHI
ZZZ
ABCDEFGHI
YYYY 1
