Pluggable transceiver SFP (1000 Mbps)
Type
Property
Article number
SFP992-1 1 x 1000 Mbps, LC port optical for glass FO cable
(multimode), up to max. 750 m
6GK5 992-1AL00-8AA0
SFP992-1+ 1 x 1000 Mbps, LC port optical for glass FO cable
(multimode), up to max. 2 km
6GK5 992-1AG00-8AA0
SFP992-1LD 1 x 1000 Mbps LC port optical for glass FO cable
(single mode) up to max. 10 km
6GK5 992-1AM00-8AA0
SFP992-1LD (C)* 1 x 1000 Mbps LC port optical for glass FO cable
(single mode) up to max. 10 km, varnished
6GK5 992-1AM00-8FA0
SFP992-1LD+ 1 x 1000 Mbps LC port optical for glass FO cable
(single mode) up to max. 30 km
6GK5 992-1AM30-8AA0
SFP992-1LH 1 x 1000 Mbps LC port optical for glass FO cable
(single mode) up to max. 40 km
6GK5 992-1AN00-8AA0
SFP992-1LH+ 1 x 1000 Mbps LC port optical for glass FO cable
(single mode) up to max. 70 km
6GK5 992-1AP00-8AA0
SFP992-1ELH 1 x 1000 Mbps LC port optical for glass FO cable
(single mode) up to max. 120 km
6GK5 992-1AQ00-8AA0
*
Pluggable transceivers with the supplement (C) in the type name have varnished printed circuit
boards (conformal coating).
Bidirectional plug-in transceiver SFP
Bidirectional plug-in transceivers feature only one fiber connection. They transmit and
receive on two different wavelengths. To establish a connection, you need two matching
bidirectional SFPs. The connected SFPs must respectively transmit on the wavelength at
which the connection partner receives.
Type
Properties
Article number
SFP992-1BXMT 1 x 1000 Mbps LC port optical for glass FO
(multimode) with max. 500 m, transmits at 1550
nm, receives at 1310 nm
6GK5 992-1AL00-8TA0
SFP992-1BXMR 1 x 1000 Mbps LC port optical for glass FO
(multimode) with max. 500 m, transmits at 1310
nm, receives at 1550 nm
6GK5 992-1AL00-8RA0
SFP992 interfaces (1000 Mbps)
Pluggable transceiver
Twisted pair
Fiber-optic cables
1000 Mbps
1000 Mbps
Max. segment length / km
SFP992-1 - 1x LC, multimode 0.750
SFP992-1+
-
1x LC, multimode
2
SFP992-1LD
SFP992-1LD (C)
- 1x LC, single-mode 10
SFP992-1LH
-
1x LC, single-mode
40
