Communications processors for PCs
7.4 CP 1626
Industrial Ethernet
System Manual, 09/2019, C79000-G8976-C242-10
305
Features
CP 1626
Required slot on the PC
PCI Express x1
Number and type of the interfaces for Industrial Ethernet
4x RJ45
Gigabit Ethernet
-
Own microprocessor ●
Optional external power supply 12 to 24 V DC
●
Functions
● In PROFINET IO controller mode, up to 256 PN IO RT devices or 64 PN IO IRT devices
can be operated.
In PROFINET IO devices mode, up to 512 submodules can be operated.
● Transmission rate 100 Mbps
● Autosensing, autocrossover and autonegotiation
● IRT (Isochronous Real Time)
● LLDP
● DCP
● Network management and diagnostics using SNMP
● Supported protocols:
ISO
TCP/UDP
PN
MRP
OPC
PG/OP
S7/S5
IT
●
●
●
● Suitable / available or according to the specified standard.
Article numbers
Component
Description
Article number
CP 1626 Communication processor for connecting to PROFINET IO as a
controller and device with main supply disconnection and series
machines support, with Ethernet real-time ASICs
6GK1162-6AA01
