Parameters for the "INIT_1_OK" transition
The following table shows the parameters for the "INIT_1_OK" transition:
No. Column 1 Column 2 Column 3 Meaning
1 NP111\CFC_NP111\Motor.FbkRunOut.Value = TRUE Motor on?
2 FC111\CFC_FC111\CTRL_PID.SP_ExtAct.Val‐
ue
= TRUE External setpoint active?
Parameters for the "DOSE_REA2" transition
The following table shows the parameters for the "DOSE_REA2" transition:
No. Address 1 Operator Address 2 Meaning
1 FC111\ADDIT\CFC_SETP\
PARA_DOS_RM1_SEL.Out.Value
= 1 Dosing in reactor 2?
Parameters for the "INIT_2_OK" transition
The following table shows the parameters for the "INIT_2_OK" transition:
No. Column 1 Column 2 Column 3 Meaning
1 NP111\CFC_NP111\Motor.FbkRunOut.Value = TRUE Motor on?
2 FC111\CFC_FC111\CTRL_PID.SP_ExtAct.Val‐
ue
= TRUE External setpoint active?
Parameters for the "INIT_OK" transition
The following table shows the parameters for the "INIT_OK" transition:
No. Column 1 Column 2 Column 3 Meaning
1 FC111\CFC_FC111\DOSE.DQ1_
SP.Value
< FC111\CFC_FC111\DOSE.DQ_
Out.Value
Setpoint of coarse dos‐
ing is less than the dos‐
ing quantity?
Parameters for the "END_DOSE" transition
The following table shows the parameters for the "END_DOSE" transition:
No. Column 1 Column 2 Column 3 Meaning
1 FC111\CFC_FC111\DOSE.DosEnd.Value = TRUE Dosing ended?
Parameters for the "CLOSE_OK" transition
The following table shows the parameters for the "CLOSE_OK" transition:
No. Column 1 Column 2 Column 3 Meaning
1 NP111\CFC_NP111\Motor.FbkRunOut.Value = FALSE Motor off?
Creating SFCs
7.3 Setting parameters
PCS 7 SMART Getting Started - Part 1 (V9.0 with APL)
126 Getting Started, 12/2017, A5E42181435-AA
