Siemens SIMATIC PCS 7 SMART - Parameters for the Steps

Table 7-1 Entries in the "Properties - START" dialog box
No. Column 1 Column 2 Meaning
1 FC111\CFC_FC111\ CTRL_PID.ModLiOp.Value TRUE Activate automatic mode
2 FC111\CFC_FC111\ CTRL_PID.AutModLi.Value TRUE Controller automatic mode
3 FC111\CFC_FC111\ CTRL_PID.SP_ExtLi.Value TRUE Select external setpoint
4 FC111\CFC_FC111\ DOSE.ModLiOp.Value TRUE Activate automatic mode
5 FC111\CFC_FC111\ DOSE.AutModLi.Value TRUE Dosing automatic mode
6 FC111\CFC_FC111\ DOSE.StartAut.Value FALSE Dosing stop; no start
7 FC111\CFC_FC111\DOSE.RstDQ_Li.Value TRUE Reset dosing quantity via intercon‐
nection
8 LI111\CFC_LI111\INT_P.OutTrkOn.Value TRUE Tracking
9 LI111\CFC_LI111\INT_P.Hold.Value FALSE Hold output value
10 NK111\CFC_NK111\ Valve.AutModOp TRUE Valve in automatic mode
11 NK112\CFC_NK112\ Valve.AutModOp TRUE Valve in automatic mode
12 NK113\CFC_NK113\ Valve.AutModOp TRUE Valve in automatic mode
13 NK114\CFC_NK114\ Valve.AutModOp TRUE Valve in automatic mode
14 NP111\CFC_NP111\ Motor. AutModOp TRUE Motor in automatic mode
7.3.2 Parameters for the steps
Parameters for the step "INIT_LINE1" in the "Initialization" tab
The following table shows the parameters for the "INIT_LINE1" step:
No. Column 1 Column 2 Meaning
1 NK111\CFC_NK111\Valve.OpenAut.Value TRUE Open valve
2 NK112\CFC_NK112\Valve.OpenAut.Value TRUE Open valve
3 NK113\CFC_NK113\Valve.OpenAut.Value TRUE Open valve
4 NP111\CFC_NP111\Motor.StartAut.Value TRUE Switch on motor
5 FC111\\CFC_FC111\DOSE.RstDQ_Li.Value FALSE Do not reset dosing quantity
via interconnection
Parameters for the step "INIT_LINE2" in the "Initialization" tab
The following table shows the parameters for the "INIT_LINE2" step:
No. Column 1 Column 2 Meaning
1 NK111\CFC_NK111\Valve.OpenAut.Value TRUE Open valve
2 NK112\CFC_NK112\Valve.OpenAut.Value TRUE Open valve
3 NK114\CFC_NK114\Valve.OpenAut.Value TRUE Open valve
4 NP111\CFC_NP111\Motor.StartAut.Value TRUE Switch on motor
